Model FSEX-24PM*-MOD Explosion Proof Synchronized Fire Alarm system strobe light. UL1638 models 24VDC

Log in or Create an Account to see pricing and buy online.
$ 2,792.43

Mountings ordered separately. Pictures shown w/ Pendent Mount

Datasheet

Installation

Federal Signal’s Model FSEX explosion-proof strobe light produces between 60 - 80 high-intensity flashes per minute. This warning light operates on 24VDC and is unique to the market because it covers an entire range of possible mounting configurations–including dome up. This light is designed for use in alarm notification systems and is compatible with fire alarm and suppression supervised control panels and power boosters.
    The FSEX is UL Listed for Class I, Division 1, Groups C and D; Class II, Division 1,Groups E, F and G; Class I, Division 2,Groups A, B; and Class III. The FSEX is UL and cUL listed, and Marine Rated.
    The 24VDC FSEX features a voltage in-rush limiting PCB design that provides greater compatibility with factory automation control systems and less electrical interference with in-rush sensitive devices.
    The FSEX is Type 4X rated; constructed to IP66. Corrosion resistance is achieved with a powder coat finish applied over the copper-free aluminum housing. Federal Signal’s Model FSEX is rated at 850 candela per UL1638 and @ two million peak candela . The FSEX can be paired with a pendant, ceiling or wall mount. For easy installation, the mounting box is first installed and the fixture is then threaded onto the mounting box, making the electrical connection. Electrical continuity is made when
    five threads are engaged. The FSEX-HI-MOD contains a supervisory diode and four wire leads, for use in fire alarm applications.
    Synchronize with the Federal Signal SSM module or by installing on an indicating circuit programmed with the System Sensor sync protocol. Federal Signal’s Model FSEX is specifically designed for explosion proof atmospheres and/or corrosive environments. Because it is easy to install and requires very low maintenance, it is ideal for use in areas such as oil rigs, mines, refineries, and chemical plants.
